CARATTERISTICHE TECNICHE


1)1) 300 MHz MIPS Processor

2) Operating System: Bootloader 76 Software system: Gemini v5.00

3) OLED - Display

4) MPEG-2 / H. 264 Hardware decoding

5) 05 Tuner: DVB-S, optional: DVB-C, DVB-T

6) Tuner Module, Plug & Play

7) 1 x Smartcard-Reader

8) V. 24/RS232 Interface

9) 10/100Mbit Ethernet Interface

10) 1 x Scart (RGB, FBAS or S-Video)

11) DVI

12) 2 x USB 2.0

13) Analog modem

14) S/PDIF Interface for digital bit stream out (AC-3)

15) 64 MByte Flash, 256 MByte RAM

16) SATA

17) For use either as internal SATA HDD 2, 5

18) Or to use for extern eSATA

19) Unlimited channel lists for TV/Radio

20) Channel-change time < 1 second

21) Automatic service scan

22) Directly bouquet-lists

23) EPG (electronic program guide)

24) Multiple LNB-Switching control (supports DiSEqC)

25) OSD in many languages and skin-support

26) Videotext Decoder

27) Extern 12V power supply

** DreamBox DM800 technical data

* DBS-Tuner mit DVB-S2:

1) Frequency Range 950...2150 MHz

2) Demodulation DVB-S (QPSK); DVB-S2 (8PSK, QPSK)

3) Symbol rate DVB-S: 2...45 Mbaud/s, SCPC/ MCPC

4) DVB-S2: 10 31 Mbaud/s (8PSK), 10 30 Mbaud/s (QPSK)

** Video decoder:

1) Video Compression MPEG-2 and MPEG-1 compatible, H. 246

2) Video Formats 4: 3 / 16: 9

3) Letterbox for 4: 3 TV-Device

** Audio decoder:

1) Audiokompression MPEG-1 & MPEG-2 Layer I and II, MP3

2) Audio Mode Dual (main/sub), Stereo

3) Frequency: 32 KHz, 44.1 KHz, 48 KHz, 16 KHz, 22.05 KHz, 24 KHz

** Output analog:

1) Output Level L/R 0, 5 Vss on 600 Ohm

2) THD > 60 dB (1 KHz)

3) Crosstalk < -65 dB

** Output digital:

1) Output Level 0, 5 Vss on 75 Ohm

2) Sampled Data Filtering 32 KHz, 44.1 KHz, 48 KHz

3) S/PDIF-Output optical, Toslink

** Ausgang Video: Ausgangspegel FBAS 1 Vss +/- 0.3 dB an 75 Ohm

** Video parameter:

1) Input Level FBAS 1 Vss +/- 0.3 dB on 75 Ohm

2) Teletext filter in conformity with ETS 300 472 Standard

** TV-Scart: Output: FBAS, RGB, S-Video

** Serielle Interface RS232:

1) Typ RS232 bidirectional

2) Bitrate 115, 2 kBit/s max.

3) Plug Connector SUB-D-9

4) Function: Update of Firmware

** Ethernet:

1) 10/100 MBit compatible interface

2) Function: Update of Firmware

** Analoge modem: Analoge modem for Internet connection

** SATA Interface: for use either as internal HDD 2, 5 or eSATAor internal 2, 5" HDD

** USB: 2 x USB 2.0 Host

** LNB power and polarisation per tuner:

1) LNB Current 500mA max.; Short-circuit-protected

2) LNB Voltage vertical < 14V no load, > 11, 5V at 400mA

3) LNB Voltage horizontal < 20V no load, > 17, 3V at 400mA

** Count of active satellite position:

1) DiSEqC 1.0/1.2 SAT POSITION / SAT OPTION

2) DiSEqC - Rotor Control

** Power consumption:

1) < 15W at 12V

2) External PSU

3) Input: 110-240V AC / 50-60Hz / 0, 6A

4) Output: 12V = / 3, 0A

** Physical specification:

1) Ambient Temperature +15C...+35C

2) Humidity < 80%

** Size (W x D x H): 195 mm x 140 mm x 40 mm

** Weight: 1.8 kg without HDD

** Multi-language: English, German, Swedish, Norwegian, Finnish, French, Czech, Denish, Greek, Hungarian, Italian, Polish, Portuguese, Romanian, Russian, Slovak, Turkish, Dutch, Polish, Spanish, Arabic
